VICTOR 140 Clamp Leaker Function Measurement Of AC Leakage Current, AC Current And On-Line AC Current Four Bits LCD Display

Introduction
VICTOR140 High Accuracy Clamp Leaker is specially designed for measurement of AC leakage current; by adopting up-to-date CT
technology
and digital integration technology, it is a product with relatively small size, high accuracy and perfect function compared with
similar leakers in the world.
The leaker could be widely applied in those fields as electricity, communications, meteorology, railroad, oilfield, construction,
measurement, scientific & research teaching institutes, industrial and mining establishments.
Clamp core of VICTOR140 High Accuracy Clamp Leaker adopts special alloy; in addition, with utilization of magnetic shielding
technology, it is basically free from influences of external magnetic field so as to ensure high precision, high stability and
high reliability of perennial continuous measurement.
VICTOR140 High Accuracy Clamp Leaker could be used for AC Line current measurement and on-line current measurement with voltage
lower than
AC600V; it also have those functions as peaking holding, data holding and data storage; with convenient use, it is an essential
Function
Measurement of AC leakage current, AC current and on-line AC current
Power
DC3V Button-type battery LR-44×2 or SR-44×2
Test Mode
Clip-on CT,integral mode
Display Mode
Four Bits LCD display
Dimension
Width × Height× Thickness:
64mm×160mm×23mm
LCD Dimension
35mm×21.5mm;display domain:32mm×15mm
Clamp Mouth
φ40mm
Sampling Rate
about 2 times/s
Range
0.00mA～300.0A(50/60Hz)
Resolution
- 4 -0.01mA
- 4 -

Measuring range
30mA/300mA,30A/300A,second-range manual switch,Automatic switch in all ranges
Measurement accuracy
(below 23℃±1℃,
70%RH)
0.00mA～9.99mA: ±1.2%±5dgt
10.0mA～300.0mA: ±1.5%±5dgt
0.00A～9.99A: ±1.2%±5dgt
10.0A～99.9A: ±1.5%±5dgt
100.0A～199.9A: ±2%±5dgt
200.0A～300.0A: ±4%±5dgt
Line voltage
Line test under AC600V
Data Storage
60 groups, "FU" symbol flickering means storage is full
Peak Holding
Peak value capture and holding function, pressHOLD button continually to show peak value in the course of testing.
Data Holding
Data holding function:displayed by "DH" symbol
Overflow display
- 5 -Outrange overflow display:displayed by "OL" symbol
- 5 -

Automatic shutdown
After starting up the leaker for 5 minutes, it will shut down automatically to reduce battery consumption.
Battery voltage
When battery voltage reduced to 2.5V～2.7V, battery low voltage symbol will filker to remind replacing battery; at this time,
measurement accuracy will decrease.
Leaker Quality
About 120g(with battery)
Rating Power
about 5mW
Working temperature and humidity
-0℃～40℃;below 80%rh
Storage temperature and humidity
-10℃～60℃;below 70%rh
Insulation strength
AC2kV/rms (between core and box)
Applicable safety rules
IEC1010-1,IEC1010-2-032,pollution, etc 2,CAT Ⅲ(600V)
